rCTOOL is an open-source R package for running C-TOOL simulations of soil organic carbon dynamics in agricultural systems. It provides a user-friendly R interface for defining carbon inputs, management schedules, soil parameters, temperature forcing, scenario simulations, and parameter calibration.
The package builds on the C-TOOL model framework (Petersen, Olesen,
and Heidmann 2002; Taghizadeh-Toosi et al. 2014) and aims to make
C-TOOL-based simulations easier to configure, reproduce, document, and
extend.
Once available on CRAN, rCTOOL can be installed with:
install.packages("rCTOOL")The development version can be installed from GitHub:
# install.packages("devtools")
devtools::install_github("francagiannini/rCTOOL")This is a simple example of the potential use of rCTOOL. The example corresponds to one of the treatments presented by (Jensen et al. 2021) and (Jensen et al. 2022) containing the C inputs for the treatment of the spring barley crop with 4 DM Mg/ha straw incorporated into the soil at a long-term experimental station Askov, Denmark.
library(rCTOOL)
library(ggplot2)
# load data ----
data('basic_example')
data('scenario_temperature')The basic_example dataset contains annual carbon inputs
and monthly management allocation information.
head(basic_example, 2)
#> mon yrs id year Cin_top Cin_sub Cin_man manure_monthly_allocation
#> 1 1 1951 1 1951 3.566 0.39 0 0
#> 2 2 1951 1 1952 3.566 0.39 0 0
#> plant_monthly_allocation
#> 1 0
#> 2 0The scenario_temperature dataset contains monthly
temperature data.
head(scenario_temperature, 2)
#> month yr Tavg
#> 1 1 1951 0.890000
#> 2 2 1951 1.170714A standard rCTOOL simulation requires five main inputs:
# define timeperiod
period <- define_timeperiod(
yr_start = 1951,
yr_end = 2019
)
# get annual Carbon inputs
cin <- define_Cinputs(
management_filepath = basic_example
)
# get management
management <- management_config(
management_filepath = basic_example,
grain_monthly_allocation = rep(0, 12),
grass_monthly_allocation = rep(0, 12),
f_man_humification = 0.192
)
# get soil configuration
soil <- soil_config(Csoil_init = 105,
f_hum_top = 0.533,
f_rom_top = 0.405,
f_hum_sub = 0.387,
f_rom_sub = 0.610,
Cproptop = 0.55,
clay_top = 0.11,
clay_sub = 0.20,
phi = 0.035,
f_co2 = 0.628,
f_romi = 0.012,
k_fom = 0.12,
k_hum = 0.0028,
k_rom = 3.85e-5,
ftr = 0.0025
)Initial soil pools are calculated before running the simulation. They depend on the initial soil carbon stock, the initial C:N ratio, and the distribution of carbon among FOM, HUM, and ROM pools.
# initialize soil pools
soil_pools <- initialize_soil_pools(
cn = 12,
soil_config = soil
)
soil_pools <- c(soil_pools[[1]], soil_pools[[2]])The monthly simulation is then run with run_ctool(). The
verbose argument can be used to run additional diagnostic
checks during the simulation.
# run rCTOOL
output <- run_ctool(
time_config = period,
cin_config = cin,
m_config = management,
t_config = scenario_temperature,
s_config = soil,
soil_pools = soil_pools,
verbose = FALSE
)The resulting output contains monthly carbon pools, soil carbon stocks, transport fluxes, and CO2 emissions.
head(output)
#> mon yrs FOM_top FOM_top_decomposition substrate_FOM_decomp_top
#> 1 1 1951 3.435048 -0.1454518 0.1454518
#> 2 2 1951 3.195740 -0.2393079 0.2393079
#> 3 3 1951 2.915547 -0.2801936 0.2801936
#> 4 4 1951 2.668412 -0.5324143 0.5324143
#> 5 5 1951 2.416203 -0.6801291 0.6801291
#> 6 6 1951 2.267384 -0.7193794 0.7193794
#> FOM_humified_top em_CO2_FOM_top FOM_tr FOM_sub FOM_sub_decomposition
#> 1 0.02782131 0.1172668 0.0003636294 0.1375258 -0.004587808
#> 2 0.04577366 0.1929360 0.0005982698 0.1307436 -0.007380504
#> 3 0.05359408 0.2258990 0.0007004840 0.1223929 -0.009051156
#> 4 0.10183764 0.4292456 0.0013310358 0.1324329 -0.022491038
#> 5 0.13009180 0.5483369 0.0017003226 0.1425719 -0.038361325
#> 6 0.13759943 0.5799816 0.0017984486 0.1540850 -0.052685398
#> substrate_FOM_decomp_sub FOM_humified_sub em_CO2_FOM_sub HUM_top
#> 1 0.004587808 0.0009878393 0.003599969 25.95689
#> 2 0.007380504 0.0015891579 0.005791346 25.96039
#> 3 0.009051156 0.0019488800 0.007102276 25.96077
#> 4 0.022491038 0.0048427332 0.017648305 25.96145
#> 5 0.038361325 0.0082598971 0.030101428 25.95782
#> 6 0.052685398 0.0113441328 0.041341265 25.94876
#> HUM_top_decomposition substrate_HUM_decomp_top HUM_romified_top
#> 1 -0.02462729 0.02462729 0.0002955275
#> 2 -0.04226870 0.04226870 0.0005072243
#> 3 -0.05321946 0.05321946 0.0006386335
#> 4 -0.10115380 0.10115380 0.0012138456
#> 5 -0.13372738 0.13372738 0.0016047285
#> 6 -0.14665546 0.14665546 0.0017598655
#> em_CO2_HUM_top HUM_tr HUM_sub HUM_sub_decomposition
#> 1 0.01546594 0.008865824 15.42058 -0.01162135
#> 2 0.02654474 0.015216730 15.42507 -0.01924719
#> 3 0.03342182 0.019159005 15.43030 -0.02481767
#> 4 0.06352458 0.036415367 15.43801 -0.05240850
#> 5 0.08398079 0.048141856 15.44536 -0.07665266
#> 6 0.09209963 0.052795966 15.45048 -0.09220968
#> substrate_HUM_decomp_sub HUM_romified_sub em_CO2_HUM_sub ROM_top
#> 1 0.01162135 0.0001394562 0.007298207 28.21587
#> 2 0.01924719 0.0002309662 0.012087233 28.21598
#> 3 0.02481767 0.0002978120 0.015585495 28.21612
#> 4 0.05240850 0.0006289019 0.032912535 28.21638
#> 5 0.07665266 0.0009198319 0.048137870 28.21673
#> 6 0.09220968 0.0011065161 0.057907677 28.21712
#> ROM_top_decomposition substrate_ROM_decomp_top em_CO2_ROM_top ROM_tr
#> 1 -0.0003677493 0.0003677493 0.0002309465 9.193731e-07
#> 2 -0.0006306740 0.0006306740 0.0003960633 1.576685e-06
#> 3 -0.0007937270 0.0007937270 0.0004984605 1.984317e-06
#> 4 -0.0015058543 0.0015058543 0.0009456765 3.764636e-06
#> 5 -0.0019886082 0.0019886082 0.0012488460 4.971521e-06
#> 6 -0.0021805722 0.0021805722 0.0013693994 5.451431e-06
#> ROM_sub ROM_sub_decomposition substrate_ROM_decomp_sub em_CO2_ROM_sub
#> 1 31.69002 -0.0003282270 0.0003282270 0.0002061265
#> 2 31.68991 -0.0005432775 0.0005432775 0.0003411783
#> 3 31.68977 -0.0007001122 0.0007001122 0.0004396704
#> 4 31.68947 -0.0014760401 0.0014760401 0.0009269532
#> 5 31.68904 -0.0021556707 0.0021556707 0.0013537612
#> 6 31.68853 -0.0025906327 0.0025906327 0.0016269173
#> C_topsoil C_subsoil SOC_stock C_transport em_CO2_top em_CO2_sub em_CO2_total
#> 1 57.60781 47.24813 104.8559 0.009230373 0.1329637 0.01110430 0.1440680
#> 2 57.37211 47.24572 104.6178 0.015816577 0.2198768 0.01821976 0.2380965
#> 3 57.09243 47.24246 104.3349 0.019861474 0.2598193 0.02312744 0.2829468
#> 4 56.84625 47.25992 104.1062 0.037750168 0.4937159 0.05148779 0.5452037
#> 5 56.59075 47.27697 103.8677 0.049847151 0.6335666 0.07959306 0.7131596
#> 6 56.43326 47.29310 103.7264 0.054599866 0.6734506 0.10087586 0.7743265The topsoil SOC trajectory can be visualized as follows.
output$time <- as.Date(
paste(output$yrs, output$mon, "01", sep = "-")
)
ggplot(output, aes(x = time, y = C_topsoil)) +
geom_line() +
geom_smooth() +
theme_classic() +
labs(
x = "Year",
y = "Topsoil SOC stock (Mg C ha-1)"
)
##
Output variables
The rCTOOL output includes time, carbon stocks, pool sizes, transport fluxes, and CO2 emissions.
mon: month of the year (1-12);yrs: year of the simulation.C_topsoil: carbon stock in the topsoil (0-25 cm).C_subsoil: carbon stock in the subsoil (26-100
cm).SOC_stock: total Soil Organic Carbon stock in the soil
(0-100 cm).C_transport: carbon transported to the subsoil.em_CO2_top: total CO2 emissions from the topsoil.em_CO2_sub: total CO2 emissions from the subsoil.em_CO2_total: total CO2 emissions from the soil.FOM_top: FOM in the topsoil.FOM_top_decomposition: monthly decomposition of FOM in
the topsoil.substrate_FOM_decomp_top: substrate for FOM
decomposition in the topsoil.FOM_humified_top: FOM that has been “humified” in the
topsoil (becomes part of topsoil HUM).em_CO2_FOM_top: CO2 emissions from the decomposition of
FOM in the topsoil.FOM_tr: FOM transported from the topsoil to the
subsoil.FOM_sub: FOM in the subsoil.FOM_sub_decomposition: decomposition of FOM in the
subsoil.substrate_FOM_decomp_sub: substrate for FOM
decomposition in the subsoil.FOM_humified_sub: FOM that has been “humified” in the
subsoil (becomes part of subsoil HUM).em_CO2_FOM_sub: CO2 emissions from the decomposition of
FOM in the subsoil.HUM_top: HUM in the topsoil.HUM_top_decomposition: Decomposition of HUM in the
topsoil.substrate_HUM_decomp_top: Substrate for HUM
decomposition in the topsoil.HUM_romified_top: HUM that has been “romified” in the
topsoil (becomes part of topsoil ROM).em_CO2_HUM_top: CO2 emissions from the decomposition of
HUM in the topsoil.HUM_tr: HUM transported from the topsoil to the
subsoil.HUM_sub: HUM in the subsoil.HUM_sub_decomposition: Decomposition of HUM in the
subsoil.substrate_HUM_decomp_sub: Substrate for HUM
decomposition in the subsoil.HUM_romified_sub: HUM that has been “romified” in the
subsoil (becomes part of subsoil ROM).em_CO2_HUM_sub: CO2 emissions from the decomposition of
HUM in the subsoil.ROM_top: ROM in the topsoil.ROM_top_decomposition: Decomposition of ROM in the
topsoil.substrate_ROM_decomp_top: Substrate for ROM
decomposition in the topsoil.em_CO2_ROM_top: CO2 emissions from the decomposition of
ROM in the topsoil.ROM_tr: ROM transported from the topsoil to the
subsoil.ROM_sub: ROM in the subsoil.ROM_sub_decomposition: Decomposition of ROM in the
subsoil.substrate_ROM_decomp_sub: Substrate for ROM
decomposition in the subsoil.em_CO2_ROM_sub: CO2 emissions from the decomposition of
ROM in the subsoil.rCTOOL includes a calibration module for evaluating and calibrating selected CTOOL parameters against observed SOC stocks.
The current calibration module tests combinations of:
f_hum_top: fraction of decomposed topsoil FOM entering
the HUM pool;k_hum: decomposition rate of the HUM pool.For each tested value of f_hum_top, the corresponding
f_rom_top is calculated internally as:
f_rom_top = 1 - f_hum_top - f_fom_topThe only additional data required for calibration is a two-column data frame containing observed SOC stocks by year. In this example, we create a small artificial observed dataset from the simulated output only to demonstrate the workflow.
observed <- aggregate(
C_topsoil ~ yrs,
data = output,
FUN = mean
)
observed <- data.frame(
Year = observed$yrs + 1,
SOC_obs = observed$C_topsoil
)
observed <- observed[observed$Year %in% c(1955, 1965, 1975, 1985, 1995), ]
observed
#> Year SOC_obs
#> 4 1955 56.10409
#> 14 1965 55.52216
#> 24 1975 54.62216
#> 34 1985 54.16431
#> 44 1995 53.38794The tested parameter ranges are defined using min,
max, and by.
calib <- ctool_calibrate(
time_config = period,
cinput_config = cin,
temperature_config = scenario_temperature,
management_config = management,
soil_config = soil,
observed = observed,
f_hum_top = c(min = 0.20, max = 0.60, by = 0.10),
k_hum = c(min = 0.0020, max = 0.0040, by = 0.0010),
verbose = FALSE
)
summary(calib)
#> C-TOOL calibration summary
#> =========================
#>
#> Calibration data:
#> Observations: 5
#> Tested combinations: 15
#>
#> Calibrated parameters:
#> f_hum_top
#> k_hum
#>
#> Parameter ranges:
#> f_hum_top: 0.2 to 0.6 by 0.1
#> k_hum: 0.002 to 0.004 by 0.001
#>
#> Calibration settings:
#> f_fom_top: 0.003
#> cn_init: 10
#> Ranking metric: d_index
#> Minimize metric: FALSE
#>
#> Best tested calibration:
#> f_hum_top k_hum f_rom_top d_index RMSE R2 Bias MAE n
#> 0.4 0.004 0.597 0.8678099 1.038007 0.9781859 0.4954844 0.7633362 5
#>
#> Current parameters versus best tested calibration:
#> Type d_index RMSE R2 Bias MAE n
#> Current C-TOOL parameters 0.5768270 2.460624 0.9908253 -2.2206482 2.2206482 5
#> Best tested calibration 0.8678099 1.038007 0.9781859 0.4954844 0.7633362 5
#> f_hum_top k_hum f_rom_top
#> 0.533 0.0028 0.405
#> 0.400 0.0040 0.597
#>
#> Recommended parameter set:
#> Source f_hum_top k_hum f_rom_top d_index RMSE R2
#> Best tested calibration 0.4 0.004 0.597 0.8678099 1.038007 0.9781859
#> Bias MAE n
#> 0.4954844 0.7633362 5
#>
#> Recommendation:
#> Use the best tested calibration because it improved the selected performance metric compared with the current C-TOOL parameters.The calibration output includes:
Model performance is evaluated using RMSE, MAE, mean bias, R2, and
the Willmott index of agreement, reported as d_index
(Willmott 1981).
calib$recommended_params
#> Source f_hum_top k_hum f_rom_top d_index RMSE
#> 1 Best tested calibration 0.4 0.004 0.597 0.8678099 1.038007
#> R2 Bias MAE n
#> 1 0.9781859 0.4954844 0.7633362 5If the current CTOOL parameters perform as well as or better than the
tested calibration grid, ctool_calibrate() recommends
keeping the current parameter set.
rCTOOL can also be used to compare multiple management or land-use
scenarios. The following example uses the scenario
dataset.
data('scenario')
data('scenario_temperature')The scenario dataset contains different C input
assumptions for different management s options.
For the football court scenario we assume a well-maintained stomped ryegrass cover,
for the organic dairy farming we assume a crop rotation with grass, maize and cereals for happy milking cows,
and finally for the pet cemetery we assume a less healthily reygrass and a certain number of beloved dogs and cats from Viborg municipality burred in the subsoil.
Now we will play with rCTOOL to explore the implications in terms of soil C dynamics.
First lets take a look on the C inputs distribution:
period <- define_timeperiod(
yr_start = 1951,
yr_end = 2019
)
management <- management_config(
manure_monthly_allocation = c(0, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0),
plant_monthly_allocation = c(0, 0, 0, 8, 12, 16, 64, 0, 0, 0, 0, 0) / 100,
grain_monthly_allocation = rep(0, 12),
grass_monthly_allocation = rep(0, 12),
f_man_humification = 0
)
soil <- soil_config(
Csoil_init = 100,
f_hum_top = 0.4803,
f_rom_top = 0.4881,
f_hum_sub = 0.3123,
f_rom_sub = 0.6847,
Cproptop = 0.47,
clay_top = 0.1,
clay_sub = 0.15,
phi = 0.035,
f_co2 = 0.628,
f_romi = 0.012,
k_fom = 0.12,
k_hum = 0.0028,
k_rom = 3.85e-5,
ftr = 0.003
)
soil_pools <- initialize_soil_pools(
cn = 10,
soil_config = soil
)Then define carbon inputs and run the model for each scenario.
treatment <- unique(scenario$treatment)
cin_treatment <- lapply(treatment, function(x) {
define_Cinputs(
management_filepath = subset(scenario, treatment == x)
)
})
names(cin_treatment) <- treatment
output_treatment <- lapply(treatment, function(x) {
out <- run_ctool(
time_config = period,
cin_config = cin_treatment[[x]],
m_config = management,
t_config = scenario_temperature,
s_config = soil,
soil_pools = soil_pools,
verbose = FALSE
)
out$treatment <- x
out
})
output_treatment <- data.table::rbindlist(output_treatment)The simulated trajectories can then be compared across scenarios.
plot_df <- output_treatment[
,
c("mon", "yrs", "C_topsoil", "C_subsoil", "em_CO2_total", "treatment")
]
plot_df <- reshape2::melt(
plot_df,
id.vars = c("mon", "yrs", "treatment")
)
labels <- c(
C_topsoil = "SOC topsoil",
C_subsoil = "SOC subsoil",
em_CO2_total = "CO2 emissions"
)
ggplot(plot_df, aes(x = yrs, y = value, colour = treatment)) +
geom_point(size = 0.02, alpha = 0.2) +
geom_smooth() +
facet_wrap(
variable ~ .,
scales = "free_y",
ncol = 1,
labeller = as_labeller(labels)
) +
labs(
x = "Year",
y = "Output (Mg ha-1)",
colour = "Treatment"
) +
theme_classic()
