| Type: | Package |
| Title: | Bibliographic Network Analysis |
| Version: | 0.13 |
| Date: | 2020-04-16 |
| Author: | Christian Vincenot |
| Maintainer: | Christian Vincenot <christian@vincenot.biz> |
| Depends: | R (≥ 3.0.1), foreach, graphics, igraph |
| Imports: | stringi, RCurl, splitstackshape, data.table, utils, stats, parallel, doParallel |
| Description: | Enables the user to build a citation network/graph from bibliographic data and, based on modularity and heterocitation metrics, assess the degree of awareness/cross-fertilization between two corpora/communities. This toolset is optimized for Scopus data. |
| License: | GPL-2 | GPL-3 [expanded from: GPL (≥ 2)] |
| NeedsCompilation: | no |
| Packaged: | 2020-04-19 10:47:31 UTC; kashim |
| Repository: | CRAN |
| Date/Publication: | 2020-04-19 11:20:02 UTC |
Bibliographic Network Analysis Package
Description
|
| Denis Diderot (1713-1784), French philosopher and co-founder of the modern encyclopedia. |
This package allows to detect and quantify the unification or separation of two bibliographic corpora through the creation of citation networks. This tool can be used to study the spread of concepts across scientific disciplines, or the fusion/fission of scientific communities.
Details
| Package: | Diderot |
| Type: | Package |
| Version: | 0.13 |
| Date: | 2020-04-17 |
| License: | GPL (>=2) |
A typical flow of use of the package includes the following points.
First, literature metadata, including references, from the two fields of studies to analyze are downloaded from Scopus (or built manually). This data is imported to create a bibliographic dataset using create_bibliography.
Second, a graph is created with a call to build_graph to reproduce the citation network in the bibliographic dataset.
Finally, statistical analysis can be performed on the graph to assess the fusion/fission state of the two corpora/communities. Heterocitation indices (i.e. share and balance) show how much publications or authors cite papers from the other corpus (see heterocitation and heterocitation_authors respectively). Such analysis shall always be preceded by a call to precompute_heterocitation to perform initial calculations. These metrics are completed by traditional as well as custom modularity metrics (see compute_modularity and compute_custom_modularity respectively) that translate how much the communities are separated. Publications that foster mutual awareness and cross-fertilization between the corpora/communities can be identified using the usual betweeness centrality metric (see compute_BC_ranking) and the Ji index (see compute_Ji_ranking).
Author(s)
Christian Vincenot
Maintainer: Christian Vincenot (christian@vincenot.biz)
See Also
Examples
## Not run:
# Two corpora on individual-based modelling (IBM) and agent-based modelling (ABM)
# were downloaded from Scopus. The structure of each corpus is as follows:
tt<-read.csv("IBMmerged.csv", stringsAsFactors=FALSE)
str(tt,strict.width="cut")
### 'data.frame': 3184 obs. of 9 variables:
### $ Authors : chr "Chen J., Marathe A., Marathe M." "Van Dijk D., Sl"..
### $ Title : chr "Coevolution of epidemics, social networks, and in"..
### $ Year : int 2010 2010 2010 2010 2010 2010 2010 2010 2010 2010 ...
### $ DOI : chr "10.1007/978-3-642-12079-4_28" "10.1016/j.procs.20"..
### $ Link : chr "http://www.scopus.com/inward/record.url?eid=2-s2."..
### $ Abstract : chr "This research shows how a limited supply of antiv"..
### $ Author.Keywords: chr "Antiviral; Behavioral economics; Epidemic; Microe"..
### $ Index.Keywords : chr "Antiviral; Behavioral economics; Epidemic; Microe"..
### $ References : chr "(2009) Centre Approves Restricted Retail Sale of "..
# Define the name of corpora (labels) and specific keywords to identify relevant
# publications (keys).
labels<-c("IBM","ABM")
keys<-c("individual-based model|individual based model",
"agent-based model|agent based model")
# Build the IBM-ABM bibliographical dataset from Scopus exports
db<-create_bibliography(corpora_files=c("IBMmerged.csv","ABMmerged.csv"),
labels=labels, keywords=keys)
### [1] "File IBMmerged.csv contains 3184 records"
### [1] "File ABMmerged.csv contains 9641 records"
# Build and save citation graph
gr<-build_graph(db=db,small.year.mismatch=T,fine.check.nb.authors=2,
attrs=c("Corpus","Year","Authors", "DOI"))
### [1] "Graph built! Execution time: 1200.22 seconds."
save_graph(gr, "graph.graphml")
# Compute and plot modularity
compute_modularity(gr_sx, 1987, 2018)
###[1] 0.3164805
plot_modularity_timeseries(gr_sx, 1987, 2018, window=1000)
# Compute and plot publication heterocitation
gr_sx<-precompute_heterocitation(gr,labels=labels,infLimitYear=1987, supLimitYear=2018)
###[1] "Summary of the nodes considered for computation (1987-2017)"
###[1] "-----------------------------------------------------------"
###[1] "IBM ABM IBM|ABM"
###[1] "1928 5378 153"
###[1]
###[1] "Edges summary"
###[1] "-------------"
###[1] "IBM->IBM/IBM->Other 5583/1086 => Prop 0.163"
###[1] "ABM->ABM/ABM->Other 16946/2665 => Prop 0.136"
###[1] "General Same/Diff 22529/3751 => Prop 0.143"
###[1]
###[1] "Heterocitation metrics"
###[1] "----------------------"
###[1] "Sx ALL / IBM / ABM"
###[1] "0.127 / 0.137 / 0.124"
###[1] "Dx ALL / IBM / ABM"
###[1] "-0.652 / -0.803 / -0.598"
heterocitation(gr_sx, labels=labels, 1987, 2005)
###[1] "Sx ALL / ABM / IBM"
###[1] "0.047 / 0.214 / 0.007"
###[1] "Dx ALL / ABM / IBM"
###[1] "-0.927 / -0.690 / -0.982"
plot_heterocitation_timeseries(gr_sx, labels=labels, mini=-1, maxi=-1, cesure=2005)
# Compute author heterocitation
hetA<-heterocitation_authors(gr_sx, 1987, 2018, pub_threshold=4)
head(hetA[order(hetA$avgDx,decreasing=T),c(1)], n=10)
### [1] "Ashlock D." "Evora J." "Hernandez J.J." "Hernandez M." "Gooch K.J."
### [6] "Reinhardt J.W." "Ng K." "Kazanci C." "Senior A.M." "Ariel G."
# Try to figure which publication are most impactful in terms of cross-fertilization
jir<-compute_Ji_ranking(gr_sx, labels=labels, 1987, 2018)
head(jir[,c(2,7)],n=3)
### Title Ji
### 758 A standard protocol for describing individual-based and agent-based models 200
### 4437 Pattern-oriented modeling of agent-based complex systems: Lessons from ecology 134
### 33 The ODD protocol: A review and first update 120
## End(Not run)
Function to compute baseline heterocitation values for the graph under study with random permutation of corpus attributions
Description
This function performs Monte Carlo runs with random permutations of corpus tags in the graph provided and computes the heterocitation balance on the new graphs. Permutation is repeated over several iterations (set through the "rep" argument) and provides a baseline Dx values for the graph topology considered. This can then be compared with the Dx value obtained for the original graph to evaluate whether it could merely be the result of chance (see significance_Dx).
Usage
MC_baseline_distribution(gr, labels, infYearLimit, supYearLimit, rep = 20)
Arguments
gr |
Graph file (created with build_graph) |
labels |
List of the names of the two corpora studied (e.g. c("Computer Science", "Mathematics")), present in the "Corpus" attribute |
infYearLimit |
Minimum year considered in this study |
supYearLimit |
Maximum year considered in this study |
rep |
Number of Monte Carlo iterations |
Value
This function currently plots the histograms of distribution of Dx values generated through random permutations of corpus tags among the records. Returns a list containing:
Dx1 |
Dx value for corpus 1 per iteration |
Dx1 |
Dx value for corpus 2 per iteration |
DxALL |
Global Dx value per iteration |
Author(s)
Christian Vincenot (christian@vincenot.biz)
See Also
significance_Dx, heterocitation
Builds a citation graph.
Description
Builds a citation graph based on a database of bibliographic records generated with create_bibliography. This process is automatically parallelized on multicore hardware. By default, matching between title and references is done based on the full title, publication year, and three first authors. Publication attributes present in the dataframe can be copied to graph nodes using the attrs argument.
Usage
build_graph(db, title = "Cite Me As", year = "Year", authors = "Authors",
ref = "Cited References", set.title.as.name = F, attrs = NULL,
verbose = F, makeCluster.type = "PSOCK", nb.cores=NA,
fine.check.threshold = 1000, fine.check.nb.authors = 3,
small.year.mismatch = T, debug = F)
Arguments
db |
Bibliographic database created with created_bibliography. |
title |
Name of the data frame column in which publication titles are listed. |
year |
Name of the data frame column in which publication years are listed. |
authors |
Name of the data frame column in which publication authors are listed. |
ref |
Name of the data frame column in which publication references are listed. |
set.title.as.name |
Set graph vertex ID to publication title |
attrs |
Attributes of the bibliographic database (i.e. data frame column names, such as "Authors"", "Year") to be set as vertex attributes. |
verbose |
Verbosity flag triggering a more detailed output during graph building. |
makeCluster.type |
Type of cluster to be used to parallelize the graph building process. For more options, see |
nb.cores |
Number of cores to be used for parallel computation. |
fine.check.threshold |
Title length under which citation matching is further confirmed based on publication year. This value can be reduced to increase performance on large bibliographic databases. By default, publication year check is always performed. |
fine.check.nb.authors |
Maximum number of authors to check against for citation matching. This value can be reduced to increase performance on large bibliographic databases. Default value is three authors. |
small.year.mismatch |
Flag indicating whether small year mismatches (+- 1 year) should be tolerated. It is recommended to keep this this flag to TRUE to accomodate usual inconsistencies in bibliographic databases. |
debug |
Debug flag allowing the user to browse function calls upon execution error. For more details, see |
Value
Returns a graph object.
Author(s)
Christian Vincenot (christian@vincenot.biz)
See Also
Examples
labels<-c("Corpus1","Corpus2")
# Build a bibliographical dataset from Scopus exports
db<-create_bibliography(corpora_files=c(tempfi1,tempfi2),
labels=labels, keywords=NA)
# Build graph
gr<-build_graph(db=db,small.year.mismatch=TRUE, attrs=c("Corpus","Year","Authors"), nb.cores=1)
Function to compute the Betweenness Centrality ranking.
Description
This function computes the Betweenness Centrality (BC) for each graph node (i.e. publication).
Usage
compute_BC_ranking(gr, labels, write_to_graph = F)
Arguments
gr |
Citation graph |
labels |
Labels (i.e. names) of the two corpora featured in the graph. |
write_to_graph |
Flag to indicate whether to write results to the graph (i.e. save BC values as node attributes). |
Value
If write_to_graph is FALSE, returns a list of entries (authors, title, year, corpus, BC) sorted by decreasing BC. Else, returns the graph given as input to which BC values are added as node attributes.
Author(s)
Christian Vincenot (christian@vincenot.biz)
See Also
compute_citation_ranking, compute_Ji_ranking
Examples
labels<-c("Corpus1","Corpus2")
# Build a bibliographical dataset from Scopus exports
db<-create_bibliography(corpora_files=c(tempfi1,tempfi2),
labels=labels, keywords=NA)
# Build graph
gr<-build_graph(db=db,small.year.mismatch=TRUE, attrs=c("Corpus","Year","Authors"), nb.cores=1)
# Compute BC
compute_BC_ranking(gr, labels)
Function to compute the evolution of the Ji metric for a term (e.g. publication title) present in the reference list of a bibliographic dataset.
Description
This function computes the Ji metric for a given term from a bibliographic dataset and returns its annual evolution within the timeframe specified. This metric indicates how much the term (e.g. publication title, software name) is cited simulteaneously in the references of both corpora and is thus important for cross-fertilization between the two communities. This function is run on the bibliographic dataset (created with create_bibliography) and is thus useful before graph creation or when the term to be searched is not the title of a node in the resulting graph. For instance, if the user knows that a publication (or, e.g. software or scientific database referenced only through a URL or grey literature) is cited and may have an impact on cross-fertilization between the two communities (the literature of which is represented by the two corpora) but does not have its own entry in the bibliographic database and would therefore not be featured as a node in the graph created by build_graph, the compute_Ji function can be used to assess its importance.
Usage
compute_Ji(db, pubtitle, labels, from = -1, to = -1)
Arguments
db |
Bibliographic database created with created_bibliography. |
pubtitle |
Publication title, or more generally term to be searched (e.g. software name). |
labels |
Labels (i.e. names) of the two corpora featured in the graph. |
from |
Start year of the time window considered (included) |
to |
End year of the time window considered (*excluded*) |
Value
Dataframe containing year and Ji metric value.
Author(s)
Christian Vincenot (christian@vincenot.biz)
See Also
Examples
labels<-c("Corpus1","Corpus2")
# Build a bibliographical dataset from Scopus exports
db<-create_bibliography(corpora_files=c(tempfi1,tempfi2),
labels=labels, keywords=NA)
# Compute Ji
compute_Ji(db, "Title1", labels, from=1990, to=2018)
Function to compute the Ji metric ranking for publications in a citation graph.
Description
This function computes the Ji metric for each graph node (i.e. publication). This metric indicates how much a publication is cited simulteaneously by both corpora and is thus important for cross-fertilization between the two communities.
Usage
compute_Ji_ranking(gr, labels, infLimitYear, supLimitYear, write_to_graph=F)
Arguments
gr |
Citation graph |
labels |
Labels (i.e. names) of the two corpora featured in the graph. |
infLimitYear |
Start year of the time window considered (included) |
supLimitYear |
End year of the time window considered (*excluded*) |
write_to_graph |
Flag to indicate whether to write results to the graph (i.e. save Ji values as node attributes). |
Value
If write_to_graph is FALSE, returns a list of entries (authors, title, year, corpus, citations from corpus 1, citation from corpus 2, Ji) sorted by decreasing Ji. Else, returns the graph given as input to which Ji are added as node attributes.
Author(s)
Christian Vincenot (christian@vincenot.biz)
See Also
build_graph, precompute_heterocitation, compute_Ji
Examples
labels<-c("Corpus1","Corpus2")
# Build a bibliographical dataset from Scopus exports
db<-create_bibliography(corpora_files=c(tempfi1,tempfi2),
labels=labels, keywords=NA)
# Build graph
gr<-build_graph(db=db,small.year.mismatch=TRUE, attrs=c("Corpus","Year","Authors"), nb.cores=1)
# Compute Ji ranking
compute_Ji_ranking(gr, labels, 1990, 2018)
Function to compute the citation ranking.
Description
This function computes the citation count for each graph node (i.e. publication).
Usage
compute_citation_ranking(gr, labels, write_to_graph = F)
Arguments
gr |
Citation graph |
labels |
Labels (i.e. names) of the two corpora featured in the graph. |
write_to_graph |
Flag to indicate whether to write results to the graph (i.e. save citation count values as node attributes). |
Value
If write_to_graph is FALSE, returns a list of entries (authors, title, year, corpus, citations) sorted by decreasing citation count. Else, returns the graph given as input to which citation count values are added as node attributes.
Author(s)
Christian Vincenot (christian@vincenot.biz)
See Also
compute_BC_ranking, compute_Ji_ranking
Examples
labels<-c("Corpus1","Corpus2")
# Build a bibliographical dataset from Scopus exports
db<-create_bibliography(corpora_files=c(tempfi1,tempfi2),
labels=labels, keywords=NA)
# Build graph
gr<-build_graph(db=db,small.year.mismatch=TRUE, attrs=c("Corpus","Year","Authors"), nb.cores=1)
# Compute Citation Ranking
compute_citation_ranking(gr, labels)
Function to compute the custom modularity of a citation graph over a time window.
Description
This function computes custom modularity of the citation graph. Custom modularity here stands for Newman's modularity computed over the subgraph comprising nodes that belong to a single corpus only and are within the time window, as well as direct outgoing neighbors of the former nodes (whatever their year tag). Basically, the citation graph considered thus includes publications within the time window as well as older papers that they cite.
Usage
compute_custom_modularity(gr, infLimitYear, supLimitYear)
Arguments
gr |
Citation graph |
infLimitYear |
Start year of the time window considered (included) |
supLimitYear |
End year of the time window considered (*excluded*) |
Value
Returns the custom modularity value of the subgraph restricted to the interval [infLimitYear;supLimitYear[.
Author(s)
Christian Vincenot (christian@vincenot.biz)
See Also
compute_modularity, plot_modularity_timeseries
Examples
labels<-c("Corpus1","Corpus2")
# Build a bibliographical dataset from Scopus exports
db<-create_bibliography(corpora_files=c(tempfi1,tempfi2),
labels=labels, keywords=NA)
# Build graph
gr<-build_graph(db=db,small.year.mismatch=TRUE, attrs=c("Corpus","Year","Authors"), nb.cores=1)
# Compute Custom Modularity
compute_custom_modularity(gr, 1990, 2018)
Function to compute citation graph modularity over a time window.
Description
This function computes Newman's modularity of the citation graph restricted to a given time window and ignoring nodes belonging to both corpora simultaneously.
Usage
compute_modularity(gr, infLimitYear, supLimitYear)
Arguments
gr |
Citation graph |
infLimitYear |
Start year of the time window considered (included) |
supLimitYear |
End year of the time window considered (*excluded*) |
Value
Returns Newman's modularity value of the subgraph restricted to the interval [infLimitYear;supLimitYear[.
Author(s)
Christian Vincenot (christian@vincenot.biz)
See Also
compute_custom_modularity, plot_modularity_timeseries
Examples
labels<-c("Corpus1","Corpus2")
# Build a bibliographical dataset from Scopus exports
db<-create_bibliography(corpora_files=c(tempfi1,tempfi2),
labels=labels, keywords=NA)
# Build graph
gr<-build_graph(db=db,small.year.mismatch=TRUE, attrs=c("Corpus","Year","Authors"), nb.cores=1)
# Compute Modularity
compute_modularity(gr, 1990, 2018)
Function to create a bibliographic dataset
Description
This function creates a bibliographic dataset based on two external corpus files, each representing the bibliography of a given domain.
Usage
create_bibliography(corpora_files, labels, keywords, retrieve_pubdates = F,
clean_refs = F, encoding = NULL)
Arguments
corpora_files |
Vector containing the pathes to two corpus files (e.g. Scopus exports). The CSV files should contain for each record at least Authors (comma separated), Publication Title, Publication Year, and References (semicolon separated). The inclusion of DOI (for date checking; see the retrieve_pubdates option) as well as Abstract, Author.Keywords, and Index.Keywords (for the in-depth identification of publications belonging to both corpora) are strongly recommended. |
labels |
Labels (i.e. names) given to the two corpora to be analyzed. |
keywords |
Keywords identifying the two corpora |
retrieve_pubdates |
Flag indicating whether to confirm publication dates by retrieving them (see |
clean_refs |
Attempt to clean references and keep titles only. NOT RECOMMENDED, especially if |
encoding |
Character encoding used in the input files. |
Value
Returns a dataframe containing a bibliographic dataset usable by Diderot and including all references from both corpora.
Author(s)
Christian Vincenot (christian@vincenot.biz)
See Also
Examples
## Not run:
# Two corpora on individual-based modelling (IBM) and agent-based modelling (ABM)
# were downloaded from Scopus. The structure of each corpus is as follows:
tt<-read.csv("IBMmerged.csv", stringsAsFactors=FALSE)
str(tt,strict.width="cut")
### 'data.frame': 3184 obs. of 9 variables:
### $ Authors : chr "Chen J., Marathe A., Marathe M." "Van Dijk D., Sl"..
### $ Title : chr "Coevolution of epidemics, social networks, and in"..
### $ Year : int 2010 2010 2010 2010 2010 2010 2010 2010 2010 2010 ...
### $ DOI : chr "10.1007/978-3-642-12079-4_28" "10.1016/j.procs.20"..
### $ Link : chr "http://www.scopus.com/inward/record.url?eid=2-s2."..
### $ Abstract : chr "This research shows how a limited supply of antiv"..
### $ Author.Keywords: chr "Antiviral; Behavioral economics; Epidemic; Microe"..
### $ Index.Keywords : chr "Antiviral; Behavioral economics; Epidemic; Microe"..
### $ References : chr "(2009) Centre Approves Restricted Retail Sale of "..
# Define the name of corpora (labels) and specific keywords to identify relevant
# publications (keys).
labels<-c("IBM","ABM")
keys<-c("individual-based model|individual based model",
"agent-based model|agent based model")
# Build the IBM-ABM bibliographical dataset from Scopus exports
db<-create_bibliography(corpora_files=c("IBMmerged.csv","ABMmerged.csv"),
labels=labels, keywords=keys)
### [1] "File IBMmerged.csv contains 3184 records"
### [1] "File ABMmerged.csv contains 9641 records"
# Processed output. Note the field name changes (for standardization with ISI Web
# of Knowledge format) and addition of the "Corpus" field (with identification of
# joint "IBM | ABM" publications based on keywords).
str(db, strict.width="cut")
### 'data.frame': 12504 obs. of 10 variables:
### $ Authors : chr "Chen J., Marathe A., Marathe M." "Van Dijk D., Sloot "..
### $ Cite Me As : chr "Coevolution of epidemics, social networks, and indivi"..
### $ Year : int 2010 2010 2010 2010 2010 2010 2010 2010 2010 2010 ...
### $ DOI : chr "10.1007/978-3-642-12079-4_28" "10.1016/j.procs.2010.0"..
### $ Link : chr "http://www.scopus.com/inward/record.url?eid=2-s2.0-78"..
### $ Abstract : chr "This research shows how a limited supply of antiviral"..
### $ Author.Keywords : chr "Antiviral; Behavioral economics; Epidemic; Microecono"..
### $ Index.Keywords : chr "Antiviral; Behavioral economics; Epidemic; Microecono"..
### $ Cited References: chr "(2009) Centre Approves Restricted Retail Sale of Tami"..
### $ Corpus : chr "IBM" "IBM | ABM" "IBM | ABM" "IBM" ...
## End(Not run)
Function to retrieve publication date based on Digital Object Identifier (DOI)
Description
This function retrieves precise publication date by querying the Digital Object Identifier (DOI) web server. Alternatively, if extract_date_from_doi is set to TRUE, the function will first try to extract a publication year from the publication DOI string. If create_bibliography is called with retrieve_pubdates = TRUE, it calls get_date_from_doi for each record to confirm publication dates.
Usage
get_date_from_doi(doi, extract_date_from_doi)
Arguments
doi |
Character string representing the Digital Object Identifier (DOI) of the publication |
extract_date_from_doi |
Flag indicating whether to try to simply extract publication year from the DOI string before restorting to online queries to the DOI server |
Value
Returns a date in YYYY-MM-DD format or YYYY-MM format if extract_date_from_doi is set to TRUE.
Note
Scopus records already contain the year of publication of scientific papers indexed. However, in some cases these are inaccurate and can be verified by comparing them with the date retrieved by this function. Note that
Author(s)
Christian Vincenot (christian@vincenot.biz)
See Also
Examples
## Not run:
# Query publication date from DOI server
get_date_from_doi(doi="10.1016/j.procs.2010.04.250",extract_date_from_doi=TRUE)
## End(Not run)
# Extract date from DOI string
get_date_from_doi(doi="10.1016/j.procs.2010.04.250",extract_date_from_doi=TRUE)
Function to extract the publication title from a reference using Freecite
Description
Function to extract the publication title from a reference using an online query to Freecite
Usage
get_reference_title(str)
Arguments
str |
Character string representing a reference |
Value
Returns a character string of the publication title
Author(s)
Christian Vincenot (christian@vincenot.biz)
Function to calculate the heterocitation between two corpora
Description
This function calculates the heterocitation share and heterocitation balance between two corpora A and B in the time window specified. The heterocitation share (Sx) of a publication belonging to corpus A is defined as the percentage of citations to publications belonging to corpus B (or A|B) in its reference list. The global heterocitation share for corpus A is calculated as the average heterocitation share of the publications that corpus A contains (e.g. a value of 0.2 for corpus A indicates that, on average, publications in corpus A cite only 20% of papers from corpus B). The heterocitation balance metric (Dx), on the other hand, takes into consideration the respective sizes of corpus A and B to discern how much the heterocitation share deviates from values expected in the case of well-mixedness (i.e. if A and B originated from a unique community; e.g. a value of -50% for corpus A indicates that, on average, publications in corpus A cite papers from corpus B half less frequently than expected, which suggests a lack of mutual awareness between the corpora and related communities).
Usage
heterocitation(gr, labels, infLimitYear, supLimitYear)
Arguments
gr |
Citation graph priorly preprocessed with |
labels |
Labels (i.e. names) of the two corpora featured in the graph. |
infLimitYear |
Start year of the time window considered (included) |
supLimitYear |
End year of the time window considered (*excluded*) |
Value
Returns a numerical vector containing, in this order, the heterocitation share (Sx) for corpus A, B and global, and the heterocitation balance (Dx) for A, B and global.
Note
precompute_heterocitation should be called before running this function.
Author(s)
Christian Vincenot (christian@vincenot.biz)
See Also
precompute_heterocitation, plot_heterocitation_timeseries, heterocitation_authors, MC_baseline_distribution, significance_Dx
Examples
labels<-c("Corpus1","Corpus2")
# Build a bibliographical dataset from Scopus exports
db<-create_bibliography(corpora_files=c(tempfi1,tempfi2),
labels=labels, keywords=NA)
# Build graph
gr<-build_graph(db=db,small.year.mismatch=TRUE, attrs=c("Corpus","Year","Authors"), nb.cores=1)
# Heterocitation
gr<-precompute_heterocitation(gr,labels, 1990, 2018)
heterocitation(gr,labels, 1990, 2018)
This function computes heterocitation metrics for authors
Description
This function computes heterocitation metrics for authors. The heterocitation share (Sx) and heterocitation balance (Dx) of an author are calculated as the average of these metrics for papers published by this author within the given time window. See the man page of heterocitation for definitions of heterocitation metrics.
Usage
heterocitation_authors(gr, infLimitYear, supLimitYear, pub_threshold = 0,
remove_orphans = F, remove_citations_to_joint_papers = F)
Arguments
gr |
Citation graph priorly preprocessed with |
infLimitYear |
Start year of the time window considered (included) |
supLimitYear |
End year of the time window considered (*excluded*) |
pub_threshold |
Minimum number of publications for authors to be considered. |
remove_orphans |
Do not consider publications that do not cite any other paper in the dataset (i.e. orphan nodes in the citation network) |
remove_citations_to_joint_papers |
Do not consider publications belonging to both corpora in the authors' average corpus calculation. |
Value
Returns a data frame containing author name ("Authors"), number of publications ("NbPubs"), list of publication years ("Years"), list of publications corpora ("Corpus"), list of publication heterocitation share ("Sx"), list of publication heterocitation balance ("Dx"), average heterocitation share ("avgSx"), average heterocitation balance ("avgDx"), average corpus value of publications ("avgCorpus"), regression coefficient of the heterocitation share evolution ("coeffSx"), regression coefficient of the heterocitation balance evolution ("coeffDx"), regression coefficient of the evolution of the corpus value of publications ("coeffCorpus").
Note
precompute_heterocitation should be called before running this function.
Author(s)
Christian Vincenot (christian@vincenot.biz)
See Also
precompute_heterocitation, heterocitation
Examples
labels<-c("Corpus1","Corpus2")
# Build a bibliographical dataset from Scopus exports
db<-create_bibliography(corpora_files=c(tempfi1,tempfi2),
labels=labels, keywords=NA)
# Build graph
gr<-build_graph(db=db,small.year.mismatch=TRUE, attrs=c("Corpus","Year","Authors"), nb.cores=1)
# Heterocitation
gr<-precompute_heterocitation(gr,labels, 1990, 2018)
# Author heterocitation
heterocitation_authors(gr, 1990, 2018)
Function to load a citation graph
Description
This function loads a citation graph saved on the filesystem.
Usage
load_graph(filename)
Arguments
filename |
File to load |
Value
Returns a graph object.
Note
This function basically supports only graph previously saved with Diderot's save_graph. However, as the file is actually a graphml file handled by igraph, advanced users may use this function on appropriate graphs created elsewhere, as long as they respect Diderot's structure (presence of a "Corpus"" field, etc).
Author(s)
Christian Vincenot (christian@vincenot.biz)
See Also
Examples
labels<-c("Corpus1","Corpus2")
# Build a bibliographical dataset from Scopus exports
db<-create_bibliography(corpora_files=c(tempfi1,tempfi2),
labels=labels, keywords=NA)
# Build graph
gr<-build_graph(db=db,small.year.mismatch=TRUE, attrs=c("Corpus","Year","Authors"), nb.cores=1)
## Not run:
save_graph(gr, "Saved.graphml")
# Load saved graph
gr<-load_graph("Saved.graphml")
## End(Not run)
Function to calculate the number of citations in a bibliographic database
Description
This function output the number of records and citations in a bibliographic database, and returns the latter.
Usage
nb_refs(db)
Arguments
db |
Bibliographic database |
Value
Returns the number of citations in the bibliographic database
Author(s)
Christian Vincenot (christian@vincenot.biz)
Examples
labels<-c("Corpus1","Corpus2")
# Build a bibliographical dataset from Scopus exports
db<-create_bibliography(corpora_files=c(tempfi1,tempfi2),
labels=labels, keywords=NA)
# NB refs
nb_refs(db)
Function to plot authors count timeseries
Description
This function plots and returns the annual number of new authors and cumulative number of authors in the bibliographic database.
Usage
plot_authors_count(db)
Arguments
db |
Bibliographic database created with created_bibliography. |
Value
Returns a dataframe containing year, annual number of new authors (i.e. not seen before), and cumulative number of authors.
Author(s)
Christian Vincenot (christian@vincenot.biz)
See Also
Examples
labels<-c("Corpus1","Corpus2")
# Build a bibliographical dataset from Scopus exports
db<-create_bibliography(corpora_files=c(tempfi1,tempfi2),
labels=labels, keywords=NA)
# Plot authors count
## Not run: plot_authors_count(db)
Function to plot the heterocitation share and heterocitation balance timeseries
Description
This function plots and returns annual heterocitation share and heterocitation balance values.
Usage
plot_heterocitation_timeseries(gr_arg, labels, mini = -1, maxi = -1, cesure = -1)
Arguments
gr_arg |
Citation graph |
labels |
Labels (i.e. names) of the two corpora featured in the graph. |
mini |
Start year of the time window |
maxi |
End year of the time window |
cesure |
Year before which values should be cumulated. Default value is -1, which indicates that each year in the time window should be plotted. |
Value
Returns a dataframe with year and annual values for heterocitation share (sx1, sx2 and sxall for corpus A and B and global resp.) and heterocitation balance (dx1, dx2 and dxall for corpus A and B and global resp.).
Author(s)
Christian Vincenot (christian@vincenot.biz)
See Also
precompute_heterocitation, heterocitation
Examples
labels<-c("Corpus1","Corpus2")
# Build a bibliographical dataset from Scopus exports
db<-create_bibliography(corpora_files=c(tempfi1,tempfi2),
labels=labels, keywords=NA)
# Build graph
gr<-build_graph(db=db,small.year.mismatch=TRUE, attrs=c("Corpus","Year","Authors"), nb.cores=1)
# Heterocitation timeseries
gr<-precompute_heterocitation(gr,labels, 1990, 2018)
plot_heterocitation_timeseries(gr, labels, 1990, 2018)
Function to plot graph modularity timeseries
Description
This function plots and returns annual graph modularity values for predefined corpora (representing communities). See compute_modularity for details on modularity calculation.
Usage
plot_modularity_timeseries(gr_arg, mini = -1, maxi = -1, cesure = -1, window = 1,
modularity_function = "normal")
Arguments
gr_arg |
Citation graph |
mini |
Start year of the time window |
maxi |
End year of the time window |
cesure |
Year before which values should be cumulated. Default value is -1, which indicates that each year in the time window should be plotted. |
window |
The temporal sliding window size over which modularity should be computed. |
modularity_function |
Modularity function to be used for the calculation: "custom" indicates that |
Value
Returns a dataframe containing year and annual modularity value.
Author(s)
Christian Vincenot (christian@vincenot.biz)
See Also
compute_modularity, compute_custom_modularity
Examples
labels<-c("Corpus1","Corpus2")
# Build a bibliographical dataset from Scopus exports
db<-create_bibliography(corpora_files=c(tempfi1,tempfi2),
labels=labels, keywords=NA)
# Build graph
gr<-build_graph(db=db,small.year.mismatch=TRUE, attrs=c("Corpus","Year","Authors"), nb.cores=1)
# Compute Modularity timeseries
plot_modularity_timeseries(gr, 1990, 2018)
Function to plot publication count timeseries
Description
This function plots and returns the annual number of publications.
Usage
plot_publication_curve(gr, labels, k = 1)
Arguments
gr |
Citation graph |
labels |
Labels (i.e. names) of the two corpora featured in the graph. |
k |
Text font size (multiplier of cex values) |
Value
Returns a dataframe containing year and annual publication count for each corpus and both together.
Author(s)
Christian Vincenot (christian@vincenot.biz)
See Also
Examples
labels<-c("Corpus1","Corpus2")
# Build a bibliographical dataset from Scopus exports
db<-create_bibliography(corpora_files=c(tempfi1,tempfi2),
labels=labels, keywords=NA)
# Build graph
gr<-build_graph(db=db,small.year.mismatch=TRUE, attrs=c("Corpus","Year","Authors"), nb.cores=1)
# Publication curve
plot_publication_curve(gr,labels)
This function precomputes heterocitation values for each node/publication of a graph.
Description
This function computes heterocitation values for each publication and stores them as node attributes in the graph. The heterocitation share of a publication belonging to corpus A is defined as the percentage of citations to publications belonging to corpus B (or A|B) in its reference list (e.g. a value of 0.2 for a publication in corpus A indicates that the publication cites only 20% of papers from corpus B). The heterocitation balance metric, on the other hand, takes into consideration the respective sizes of corpus A and B to discern how much the heterocitation share deviates from values expected in the case of well-mixedness (i.e. if A and B originated from a unique community; e.g. a value of -30% for a publication in corpus A indicates that it cites papers from corpus B 30% less frequently than expected).
Usage
precompute_heterocitation(gr, labels, infLimitYear, supLimitYear)
Arguments
gr |
Citation graph |
labels |
Labels (i.e. names) of the two corpora featured in the graph. |
infLimitYear |
Start year of the time window considered (included) |
supLimitYear |
End year of the time window considered (*excluded*) |
Value
Returns the graph gr with added node attributes Sx and Dx representing the heterocitation share and heterocitation balance respectively.
Note
Corpus-wide heterocitation values can be computed using heterocitation.
Author(s)
Christian Vincenot (christian@vincenot.biz)
See Also
heterocitation, plot_heterocitation_timeseries, compute_Ji_ranking
Examples
labels<-c("Corpus1","Corpus2")
# Build a bibliographical dataset from Scopus exports
db<-create_bibliography(corpora_files=c(tempfi1,tempfi2),
labels=labels, keywords=NA)
# Build graph
gr<-build_graph(db=db,small.year.mismatch=TRUE, attrs=c("Corpus","Year","Authors"), nb.cores=1)
gr<-precompute_heterocitation(gr,labels, 1990, 2018)
Function to save a graph
Description
This function saves a graph produced with Diderot. The resulting structure is actually a graphml file and can thus be exported to third party software.
Usage
save_graph(gr, filename)
Arguments
gr |
Graph object to save. |
filename |
File to save the graph to. |
Author(s)
Christian Vincenot (christian@vincenot.biz)
See Also
Examples
labels<-c("Corpus1","Corpus2")
# Build a bibliographical dataset from Scopus exports
db<-create_bibliography(corpora_files=c(tempfi1,tempfi2),
labels=labels, keywords=NA)
# Build graph
gr<-build_graph(db=db,small.year.mismatch=TRUE, attrs=c("Corpus","Year","Authors"), nb.cores=1)
## Not run: save_graph(gr, "Saved.graphml")
Function to evaluate the significance of the heterocitation balance value
Description
This function assesses to what extent the heterocitation balance (Dx value) calculated for a graph departs from baseline situation. The latter typically represents Dx values to be expected by chance, i.e. through random permutation of corpus assignation at the node/vertex level (see MC_baseline_distribution). A Shapiro-Wilk test is first executed on the control distribution (using shapiro.test) and if the normality hypothesis is not rejected, a one-sample t test (see t.test) is used to test whether value is significantly different from the control distribution. The strength of this difference is additionally assessed through Glass' delta, an estimator of effect size (Glass, McGraw, and Smith, 1981).
Usage
significance_Dx(value, control, normality_threshold=0.05)
Arguments
value |
Heterocitation balance (Dx) calculated for the citation network studied |
control |
Baseline distribution of Dx values in control experiments |
normality_threshold |
P value threshold under which the hypothesis of normality is rejected in the preliminary Shapiro-Wilk test |
Value
Returns a list containing the p-value obtained in a one-sample t test comparing value and the control distribution (with null hypothesis being that value could come from the control distribution) or NA if the control distribution is not normal based on a Shapiro-Wilk normality test, and Glass' estimator of effect size.
Author(s)
Christian Vincenot (christian@vincenot.biz)
References
Glass, G. V., McGraw, B., & Smith, M. L. (1981). Meta-analysis in social research. Beverly Hills: Sage Publications.
See Also
significance_Dx, heterocitation
Examples
## Not run:
# Heterocitation in our graph
heterocitation(gr_sx, labels=labels, 1987, 2005)
### [1] "Sx ALL / ABM / IBM"
### [1] "0.047 / 0.214 / 0.007"
### [1] "Dx ALL / ABM / IBM"
### [1] "-0.927 / -0.690 / -0.982"
# Generate a baseline distribution for Dx values obtained through chance
# Here, we run 200 iterations of node corpus permutations
baseline<-MC_baseline_distribution(gr_sx, labels, 1987, 2018, 200)
# Assess whether our observed Dx is possibly due to chance
significance_Dx(-0.927, baseline[["Dx ALL"]])
### [1] "Distribution is normal. Performing t-test."
###
### One Sample t-test
###
### data: value - control
### t = -323.0017, df = 319, p-value < 2.2e-16
### alternative hypothesis: true mean is not equal to 0
### 95 percent confidence interval:
### -0.9159834 -0.9048923
### sample estimates:
### mean of x
### -0.9104379
###
### [1] "Glass' effect size: -18.0563442219448"
## End(Not run)
